23.6" AOpen 24HX2Q P gaming monitor performance benchmarks: response, input and full specs review

The AOpen 24HX2Q P has the Display Port and this is essential for NVIDIA cards to work with AMD FreeSync. For the extremely fast frame rates, the AOpen 24HX2Q P has a maximum refresh rate of 144 Hz that allows smoother gameplay. With the AMD FreeSync support, this monitor is compatible with both AMD and NVIDIA graphics cards. The monitor has a VESA mount. For the average response rate, the AOpen 24HX2Q P scores 1.5 ms, which ensures effective synchronization with the high refresh rate. The AOpen 24HX2Q P is a relatively new monitor. The minimum response rate of AOpen 24HX2Q P is 1 ms, which is eliminates ghosting effects. In terms of pixel density, the AOpen 24HX2Q P has an excellent density of 93 pixels-per-inch, resulting in sharper text and picture quality. The brightness of AOpen 24HX2Q P is lower than other monitors. AOpen 24HX2Q P has a total input lag of 16.5 ms, which is bad among the competition. The monitor has an unimpressive contrast ratio of 1000 : 1. The monitor uses a TN panel which suffers from color shifting when viewed from horizontal and vertical angles and has slightly washed colors compared to IPS and VA panels. For graphics color quality, the AOpen 24HX2Q P has an average color depth of 6 -bit, resulting in dithered gradients and more slightly less accurate colors. Graphically demanding games may cause frame drops outside the adative refresh rate of 48 Hz.

Share Your Comments 0

Brand	AOpen
Year	2018
Model	24HX2Q P
Size	23.6"
Minimum Refresh Rate	48Hz
Maximum Refresh Rate	144Hz
AMD FreeSync	Yes
NVIDIA G-Sync	No
Maximum Resolution	1920 x 1080
Panel Type	TN
Pixel Density	93 ppi
Minimum Response Time	1ms
Average Response Time	1.5ms
Total Response + Input Lag	16.5ms
Maximum Brightness	300 cd/m^2
Price	$ 175.0
VESA Mount	Yes
Native Color Depth	6 bit
Static Contrast Ratio	1000 : 1
Display Port	Yes
Overall Combination Score	72.5/100	Very Good

Compare To

Specifications

23.6" AOpen 24HX2Q P 3D

3D	No

23.6" AOpen 24HX2Q P Audio

Speakers	2 x 2 W (watts)

23.6" AOpen 24HX2Q P Brand, series, model

Brand	AOpen
Model	24HX2Q P
Model alias	24HX2Q-P
Series	HX2

23.6" AOpen 24HX2Q P Camera

Camera	No

23.6" AOpen 24HX2Q P Certificates, standards and licenses

Certificates, standards and licenses	ENERGY STARErPTCO Certified Displays

23.6" AOpen 24HX2Q P Connectivity

Connectivity	2 x HDMI 1.4, 1 x HDMI 2.0, 1 x DisplayPort 1.2, 1 x 3.5 mm Audio In, 1 x 3.5 mm Audio Out

23.6" AOpen 24HX2Q P Dimensions, weight and color

Colors	Black

23.6" AOpen 24HX2Q P Display

Aspect ratio	1.778:116:9
Backlight	W-LED
Brightness	300 cd/m² (candela per square meter)
Coating	Anti-glare/Matte (3H)
Colors	16777216 colors 24 bits
Diagonal	599 mm (millimeters) 59.9 cm (centimeters) 23.5827 in (inches) 1.9652 ft (feet)
Dynamic contrast	100000000 : 1
FRC	Yes
Height	293.22 mm (millimeters) 29.322 cm (centimeters) 11.5441 in (inches) 0.962 ft (feet)
Horizontal viewing angle	170 ° (degrees)
Minimum response time	1 ms (milliseconds) 0.0010 s (seconds)
NTSC (1953)	72 % (percent)
Panel bit depth	8 bits (6 bits + FRC)
Panel type	TN
Pixel density	93 ppi (pixels per inch) 36 ppcm (pixels per centimeter)
Pixel pitch	0.272 mm (millimeters) 0.0272 cm (centimeters) 0.0107 in (inches) 0.0009 ft (feet)
Resolution	1920 x 1080 pixels Full HD / 1080p
Size class	23.6 in (inches)
Static contrast	1000 : 1
Vertical viewing angle	160 ° (degrees)
Width	521.28 mm (millimeters) 52.128 cm (centimeters) 20.5228 in (inches) 1.7102 ft (feet)

23.6" AOpen 24HX2Q P Ergonomics

Backward tilt	20 ° (degrees)
Forward tilt	5 ° (degrees)
Forward/backward tilt	Yes
Height adjustment	No
Landscape/portrait pivot	No
Left/right swivel	No
Removable stand	Yes
VESA interface	100 x 100 mm
VESA mount	Yes

23.6" AOpen 24HX2Q P Features

Features	AMD FreeSync technology, Blue Light FilterFlicker-free technology, HDCP (High-bandwidth Digital Content Protection)

23.6" AOpen 24HX2Q P Frequencies

Vertical frequency (digital)	48 Hz - 144 Hz (hertz)

23.6" AOpen 24HX2Q P Power supply and consumption

110V	100 V - 120 V (volts)
220V	220 V - 240 V (volts)
Alternating current frequency	50 Hz - 60 Hz (hertz)
Electric current (A)	3 A (amperes)
Power consumption (average)	28 W (watts)
Power consumption (maximum)	36 W (watts)
Power consumption (off)	0.5 W (watts)
Power consumption (sleep)	0.5 W (watts)
